Name: AltRider Universal Bar-Mounted GPS Adapter with clamp
Brand: Tarswin Metal
SKU: ALTR-2-3902
Price: 119.96 USD
Availability: InStock

AltRider Universal Bar-Mounted GPS Adapter with clamp

$119.96

Shipping calculated at checkout.

GPS Mount Option

GPS Mount with 31.75 mm (1.25 inch) clamp

GPS Mount with 25.4 mm (1 inch) clamp

GPS Mount

Free Shipping USA

In stock, ready to ship
Backordered

• Flexible Positioning: A 31.75 mm (1.25 inch) slot allows you to slide the mount along the bar to find the exact position that works best for your cockpit.
• Wide Bar Compatibility: Included aluminum shims let the adapter fit bar diameters of 12, 14, 16, 22, and 31.75 mm without buying extra parts.
• Universal GPS Fit: Compatible with the standard 2- and 4-hole AMPS pattern used by RAM Mounts, Garmin Zumo cradles, and RAM Ball sizes A, B, and C.
• Two Orientations: The GPS mount can be attached horizontally or vertically, so you can choose the viewing angle that suits your riding style.

• Material: 6061 aircraft-grade billet aluminum (CNC machined); cast stainless steel clamp (included)
• Finish: Bead-blasted, anodized black
• Clamp Size (this SKU): 31.75 mm (1.25 in)
• Compatible Bar Diameters: 12 mm, 14 mm, 16 mm, 22 mm, 31.75 mm (via included shims)
• AMPS Pattern: 2-hole (horizontal only) and 4-hole
• Hardware: Stainless steel included
• Weight: 0.6 lbs
• Dimensions: 4 × 3 × 1 in

Finding a clean GPS mounting position in a crowded cockpit is a real problem. This adapter gives you more options — on handlebars, support bars above the triple tree, near the windscreen, or anywhere else you can safely reach.

The adapter plate mounts using included stainless steel hardware and accepts GPS cradles in two orientations: horizontal or vertical. The included cast stainless steel clamp handles 31.75 mm bars directly. Aluminum shims in the box cover smaller diameters without additional parts.

The AMPS pattern mounting works with RAM Mounts, Garmin Zumo cradles, and RAM Ball sizes A, B, and C. Note that the 2-hole AMPS pattern is horizontal use only. Also compatible with the AltRider Yamaha Ténéré 700 Cowl Support.

• Flexible Mounting: Aluminum shim adapters let you mount to a wide range of bar diameters so you can place your GPS exactly where it is most useful.
• Easy to Position: A slot design gives you up to 31.75 mm of adjustment so you can fine-tune the exact location of your GPS.
• Two Orientations: The adapter accepts GPS mounts in both horizontal and vertical positions, giving you more options for screen angle and visibility.
• Universal GPS Fit: Compatible with 2- and 4-hole AMPS pattern mounts, including RAM Mounts and Garmin Zumo cradles, so it works with most popular GPS systems.
• Strong Construction: CNC machined from 6061 aircraft-grade billet aluminum with stainless steel hardware, built to handle vibration and rough conditions.

• Material: 6061 aircraft-grade billet aluminum (adapter); stamped 6061 aluminum (shims); cast stainless steel (clamp)
• Finish: Bead blasted, anodized black
• Hardware: Stainless steel
• Bar Diameter Compatibility (shims): 12 mm, 14 mm, 16 mm, 22 mm
• Bar Diameter Compatibility (clamp included): 25.4 mm (1 inch)
• Bar Diameter Compatibility (clamp optional): 31.75 mm (1.25 inch)
• AMPS Pattern: 2-hole (horizontal only) and 4-hole
• RAM Ball Compatibility: A, B, C sizes
• Adjustability: 31.75 mm (1.25 inch) slot adjustment
• Radiator Spacing: N/A
• Weight: 0.6 lbs
• Dimensions: 4 × 3 × 1 in

Finding space to mount a GPS on a motorcycle, quad, or buggy is a real problem. This adapter gives you more options. It mounts to support or brace bars commonly found above the triple tree or near the windscreen — anywhere you can safely place it and actually see it while riding.

The included aluminum shims cover bar diameters from 12 mm up to 22 mm straight out of the box. Add the included AltRider cast stainless steel clamp and you can also mount to 25.4 mm bars. A 31.75 mm clamp is available separately for larger bars. A slot design gives you room to shift the position forward or back until it sits exactly where you want it.

The adapter is compatible with RAM Mounts and Garmin Zumo cradles, and works with Ram Ball sizes A, B, and C. It also works with the AltRider Yamaha Ténéré 700 Cowl Support.

• Flexible Mounting: Adapter shims let you mount to a wide range of bar diameters so you can find the best position in your cockpit.
• Universal GPS Compatibility: Works with 2- or 4-hole AMPS pattern mounts, including RAM Mounts and Garmin Zumo cradles, so it fits the GPS system you already own.
• Two Orientations: Mount your GPS horizontally or vertically to get the viewing angle that works best for you on the trail.
• Fine Adjustment: A slot design gives you over 30 mm of position adjustment so you can dial in the exact location you want.
• Durable Construction: CNC machined from 6061 aircraft-grade billet aluminum and bead blasted for a tough, long-lasting build.

• Material: 6061 aircraft-grade billet aluminum (body and shims)
• Hardware: Stainless steel
• Finish: Anodized black, bead blasted
• AMPS Pattern Compatibility: 2-hole (horizontal only) and 4-hole
• RAM Ball Compatibility: A, B, C sizes
• Bar Diameter Compatibility: 12 mm, 14 mm, 16 mm, 22 mm (with included shims); 25.4 mm and 31.75 mm (with AltRider cast stainless steel clamps, sold separately)
• Adjustability: 31.75 mm (1.25 in) slot adjustment
• Weight: 0.6 lbs
• Dimensions: 4 × 3 × 1 in

Finding a good GPS mount position on a motorcycle cockpit is not easy. Bars vary in diameter, space is limited, and most mounts force a compromise. This adapter was designed to give you real options.

It works with support or brace bars found near the triple tree, below the windscreen, or anywhere else you can safely run a bar. Three included aluminum shims cover a wide range of bar diameters right out of the box. For larger bars, it pairs with AltRider cast stainless steel clamps, sold separately.

The adapter is compatible with GPS mounts using a 2- or 4-hole AMPS pattern — including RAM Mounts and Garmin Zumo cradles — and works with RAM Ball sizes A, B, and C. Mount your GPS horizontally or vertically depending on what works best for your riding position.

Also compatible with the AltRider Yamaha Ténéré 700 Cowl Support.
