DD23-4-8102
• Stops Mud Jamming: Raises the front fender away from the wheel so mud and debris cannot pack in and lock up the front end during serious off-road riding.
• Strong Fender Mount: A billet aluminum bracket and quill attach to the steering column with a large M10 bolt, holding the fender securely under hard off-road use.
• Protects Forks and ABS: Custom laser-cut 2 mm aluminum fork leg guards mount at three points and are shaped to cover the ABS sensor correctly, with built-in brake hose routing clips.
• DOT-Approved Brake Lines: The included braided stainless steel brake lines are street legal, UV-resistant, and built with strain reliefs for long-term durability.
• No Cutting Required: All brackets fit the factory mount points exactly — bolt on and ride, no drilling or modification needed.
• Tire Clearance Option: An optional spacer is included to maintain safe clearance if a larger off-road tire is fitted.
• Fender Material: Plastic, pre-drilled
• Bracket Material: Billet aluminum
• Quill Bolt: M10
• Fork Leg Guard Material: Aluminum, laser cut
• Fork Leg Guard Thickness: 5/64 in (2 mm)
• Fork Guard Mounting Points: 3 per side
• Brake Lines: Braided stainless steel with UV-resistant black PVC coating
• Brake Line Certification: DOT-approved, street legal
• Weight: 4.95 lbs
• Dimensions: 26 × 7 × 9 in
▶
Highlights of the DesertX High Fender KIt:
▶
Install Instructions for the High Fender Kit:
• Stops Fender Jam: High fender position keeps mud and debris from packing between the fender and tire — a common problem on the DesertX in serious off-road conditions.
• Solid Bracket Mount: Billet aluminum bracket and quill attach to the steering column with a large M10 bolt for a secure, rattle-free connection.
• Complete Fork Protection: Laser cut 2mm aluminum fork leg guards mount at three points and include correct coverage for the ABS sensor with no cutting or drilling required.
• Brake Hose Routing: Fork leg guards include built-in brake hose routing clips to keep lines neatly secured and protected from trail damage.
• DOT-Approved Brake Lines: Braided stainless steel lines with UV-resistant black PVC coating and strain reliefs replace stock lines for better durability and performance.
• Tire Clearance Option: An included optional spacer provides extra room between the fender and front tire if needed with larger off-road tires at full compression.
• Fender Material: Plastic, pre-drilled, mid-length
• Bracket Material: Billet aluminum
• Fork Leg Guard Material: Aluminum, laser cut
• Fork Leg Guard Thickness: 2mm (5/64 in)
• Fork Leg Guard Mounting Points: 3 per side
• Brake Lines: Braided stainless steel with UV-resistant black PVC coating, DOT-approved
• Weight: 4.95 lbs
• Dimensions: 26 × 7 × 9 in
▶
Highlights of the DesertX High Fender KIt:
▶
Install Instructions for the High Fender Kit:
• Mud Prevention: Raising the fender to a high mount position keeps mud and debris from jamming against the front wheel during serious off-road riding.
• Strong Bracket: The fender attaches to the steering column via a billet aluminum bracket and quill secured with a large M10 bolt — built to handle rough terrain.
• Better Fork Protection: Custom laser-cut aluminum fork leg guards mount at three points and include correct coverage for the ABS sensor, something most aftermarket guards miss.
• Integrated Hose Routing: The fork leg guards include built-in brake hose routing clips, keeping lines tidy and protected without extra hardware.
• DOT-Approved Brake Lines: The dual-sided braided stainless steel brake line kit is street legal and DOT-approved, with UV-resistant PVC coating and built-in strain reliefs for long-term durability.
• No Cutting Required: All guards mount directly to OEM mounting points straight out of the box — no drilling or modification needed.
• Tire Clearance Option: An optional spacer is included to maintain safe fender clearance if you run larger off-road tires.
• Fender Material: Plastic (pre-drilled)
• Bracket Material: Billet aluminum
• Fork Leg Guard Material: Laser-cut aluminum
• Fork Leg Guard Thickness: 5/64 in (2 mm)
• Fork Leg Guard Finish: Powder-coated
• Bracket Bolt Size: M10
• Brake Lines: Braided stainless steel with UV-resistant black PVC coating, DOT-approved
• Weight: 4.95 lbs
• Dimensions: 26 × 7 × 9 in
▶
Highlights of the DesertX High Fender KIt:
▶
Install Instructions for the High Fender Kit:
• Stops Fender Jam: High fender position keeps mud and debris from packing between the fender and tire — a common problem on the DesertX in serious off-road conditions.
• Solid Bracket Mount: Billet aluminum bracket and quill attach to the steering column with a large M10 bolt for a secure, rattle-free connection.
• Complete Fork Protection: Laser cut 2mm aluminum fork leg guards mount at three points and include correct coverage for the ABS sensor with no cutting or drilling required.
• Brake Hose Routing: Fork leg guards include built-in brake hose routing clips to keep lines neatly secured and protected from trail damage.
• DOT-Approved Brake Lines: Braided stainless steel lines with UV-resistant black PVC coating and strain reliefs replace stock lines for better durability and performance.
• Tire Clearance Option: An included optional spacer provides extra room between the fender and front tire if needed with larger off-road tires at full compression.
• Fender Material: Plastic, pre-drilled, mid-length
• Bracket Material: Billet aluminum
• Fork Leg Guard Material: Aluminum, laser cut
• Fork Leg Guard Thickness: 2mm (5/64 in)
• Fork Leg Guard Mounting Points: 3 per side
• Brake Lines: Braided stainless steel with UV-resistant black PVC coating, DOT-approved
• Weight: 4.95 lbs
• Dimensions: 26 × 7 × 9 in
▶
Highlights of the DesertX High Fender KIt:
▶
Install Instructions for the High Fender Kit:
